Factory Direct Horizontal Axially Split Case Fire Pump
Factory Direct Horizontal Axially Split Case Fire Pump
π Product Overview:
Axially split case centrifugal pump use double suction impeller and pump has the advantage of high capacity, high pressure, widely used in industrial water supply and fire fighting. The pump features easy maintenance,utilizing two housing to facilitate internal inspection and servicing without the need to disassemble the motor and coupling.
Here's an overview of its design, advantages, and common uses:
Key Features:
1.Double Suction Design: The double suction feature allows for high efficiency water intake, ensuring rapid and consistent water flow for fire suppression.
2.Single Stage Operation: Simplified design with single-stage operation for ease of maintenance and optimized performance.
3.Horizontal Split Case: The horizontal split case configuration offers stability, easy access for maintenance, and efficient operation.
4.High Performance: Engineered for demanding fire fighting applications, providing reliable and efficient water delivery under high pressure.
5.Robust Construction: Built with durable materials to withstand rigorous conditions, ensuring long-term reliability and performance.
Benefits:
Efficiency: Double suction design for rapid water intake and high-performance fire suppression.
Reliability: Single-stage operation and robust construction for dependable performance in emergencies.
Ease of Maintenance: Horizontal split case design for easy access and maintenance, minimizing downtime.
Adaptability: Suitable for a wide range of applications, from commercial to residential fire fighting systems.
Safety Assurance: Ensuring effective fire protection measures to safeguard lives and properties.
βοΈ Application Range:
-Max Flow: 75-22000 m3/h
-Max Head: 10-220 meters
-Transmission Medium: clean water/industrial water/river water/sea water/salt water/pulp water/hydrocarbons
π οΈ Specifications:
Specifications Medium temperature: Maximum 104β
Shaft seal: packing seal/mechanical seal
Flange standard: GB ISO
Working pressure: up to 2.5 MPa
Exit diameter: 80-1200 mm
Taizhou Shynpo Factory&Trading Co., Ltd.
Shynpo is the subsidiary of Shanghai Pump Manufacture Co.,Ltd. , which is the leading supplier in fluid industry since 1930 .By combining innovative technology,excellent quality and one-stop service, we offer the intelligen-tized solution for customers.
β Frequently Asked Questions (FAQ)
π’ 1. Where can this fire pump system be used?
Our EDJ fire pump systems are ideal for commercial buildings, industrial facilities, warehouses, hospitals, airports, and residential high-rise projects β anywhere fire protection is critical.
π 2. Can I customize the pump set according to my project?
Yes. We offer customized fire pump sets, including flow/head requirements, materials (cast iron, stainless steel, bronze), motor type, and control panels (3-in-1 or separate cabinets).
π 3. Do you ship internationally?
Yes! We have exported to over 60 countries, including the Middle East, Southeast Asia, Africa, South America, and Europe. We offer FOB, CIF, and EXW terms.
π§° 4. Do you offer installation or technical support?
We offer technical consultation, remote guidance, and spare parts supply. On-site service can be arranged for large projects through our authorized partners.
π 5. What is the lead time for production and shipping?
Standard systems: 30-45 working days
Shipping time depends on your port and method.
π³ 6. What are your payment terms?
Our usual terms are:
30% deposit, 70% balance before shipment
T/T (bank transfer) preferred
LC at sight is negotiable for large orders
